Description
Table Top Supports
Two full length, 1-3/4” D x 16-gauge cold rolled steel apron channels with rounded edges and dressed off end fittings for safety.
Twin Dual Center Legs
1” x 1” 16-gauge box tubing at the center of the table provides positive, direct support for each half of the table top.
End Legs
Consists of three tubes for rigid, long lasting strength. One is welded on top, the bottom tube has an extra tube inside. Outer tubes have minimum wall thickness of .072”.
Seating
Benches are 10” x 40” and individual seats are 10” x 16”. Positioned at 17” H, each provide proper knee clearance from understructure.
Table & Seat Tops
Table tops, benches & seats are made with 45lbs density particleboard core with high pressure laminated top, balanced with durable Gator™ black backer. Table and bench edges come standard with Dura-Edge extruded polyvinyl, or can be ordered with optional Premium duraBond sprayed-on edge.
Fasteners
Tops are attached with full threaded, hex head screws with a minimum holding power of 300lbs. Each fastener is machine driven and seated. The hex head permits normal maintenance of units if required.
Locks
Automatically engage when folded and when in-use. Locks are easily accessi-ble from both sides of the table.
Unitized Construction
Welded steel brackets and fittings solidly join and position legs to channel support aprons and anchor the torsion bar lift assists.
Lift Assists
Industry best dual lift assists, both concealed torsion bars and extension springs for easy operation throughout the use of the table.
Finish
End legs are available in either Black Epoxy Powder Coat or Nickel Chromium. The understructure is black powder coat.
